Shearing Machine

Gurmeet Machinery Corporation is one of the largest and reputed Shearing Machine Manufacturers in India. Our Shearing Machines are made of excellent quality of raw material by our experienced professionals ensuring low maintenance and long life. With our immense effort we have become one of the trusted Shearing Machine Manufacturers and Shearing Machine Exporters in India .

Shearing Machine is a multi-purpose machine used for the cutting of alloys and other sheet metals. Most of its models use angular shear action to cut metal into sheets or strips or other with blades, fixed at an angle as opposed to the angular movement. Shear table, Work holding device, upper and lower blades and a gauging device are a few basic components come with it for easing the work. Gurmeet Machinery Corporation is one of the most trusted Shearing Machine Manufacturers in Punjab, India. Our Shaper Machine pass quality parameters before reaching the final customers.

Salient Features Of Our Shearing Machines:

• Ease The Cutting Work: With this Shear Machine, cutting sheets, plates or bars become easier and get done in half of the time before, which not only boost your productivity but also save your time and money.
• Sharp Blades: The blades of Hydraulic Shearing Machine are made of stainless steel or other specific metal, which further guarantees the precision and fine cutting edges.
• Require Low Upkeep: Since only industry-grade material and advanced technology has been implemented for its production, it’ll guarantee the need for low maintenance.

Send Us Your Enquiry!
We are one of the preeminent Sheet Shearing Machines Exporters and Suppliers in India. To discuss your requirements with our experts, drop your enquiry or dial our number now. We have a capable team to cater to your possible customized demands.

Gurmeet Machinery Corporation is one of the leading expertise in manufacturing and exporting Hydraulic Shearing Machine. We provide these machines in the market at very economical price. Shearing are available in Capacities (size) of 4 feet / 5 / 6 / 8 / 10 / 12 feet & 13 feet length thickness of machine is 0.100 mm up to 4 mm capacities, rolling key clutch, spring loaded mechanical hold down pads, increased productivity & reliability.

SHEARING SIZES
Shearing are available in Capacities (size) of 4 feet / 5 / 6 / 8 / 10 / 12 feet & 13 feet length thickness of machine is 0.100 mm up to 4 mm capacities, rolling key clutch, spring loaded mechanical hold down pads, increased productivity & reliability.

BLADES (KNIVES)
Shearing’s are provided with high quality single segment (one piece blade) aisihchcr D2 grade knives for longer tool life. knives are precisely ground with perfectly shape and honed cutting edge. Providing long intervals between re-sharpening. The Knife blades are four edged.

CLUTCH AND BRAKE
Rolling key type clutch is manufactured from was material duly heat treated to provide long trouble free services. Spring operated powerful heavy duty brakes is of release type works according to timing adjustment to provide longer life to the brake.

LUBRICATION SYSTEM
All bearing part / bushings / guide surface & all the moving parts are lubricated through Hand-operated lubrication system.

ACCESSORIES
Hand Operated back gauge, manual operated lubrication oil pump, T-Slote for front supporters, front scale gauge, mechanical hold down system, gear cover & fly wheel cover.

FRAME
The Body Frame is rigid steel constructed from steel plates with safeguards steel plates designed for maximum rigidity to eliminate deflection and to withstand continuous high speed performance at full capacity.

MECH. HOLD DOWN SYSTEM
Spring loaded mechanical hold down pads hold the sheet securely, to avoid slipping and bowing resulting in clean square cuts. Spring loaded mechanical hold down is provided in all machine.

FINGER GUARD
To….avoid….the accident, fitted in front of hold down for operator protection without obstructing viewing.

BACK GAUGE
This is standard Mechanical Equipment provided on all the shearing machine. Scale on the back gauge gives instantaneous reading of distance between shear and back gauge. Each machine provided steel fabricated screw type mechanical back gauge.


Technical Specification:-

MODEL	GMC- 4	GMC - 6	GMC - 8	GMC - 10	GMC - 12	GMC -16
Cutting Length	1500 mm	2500 mm	3000 mm	3000 mm	3000 mm	2500 mm
Cutting Capacity MS	4 mm	6 mm	8 mm	10 mm	12 mm	16 mm
Cutting Capacity SS	2 mm	4 mm	6 mm	8 mm	10 mm	12 mm
Variable rack angle	0.5-3°	0.5-3°	0.5-3°	0.5-3°	0.5-3°	1-4 °
Stroke/Mint	26/13	20/10	25/10	12/5	15/17	4/1
No of Hold down	8	13	15	15	15	30
Electrical Motor	5 HP	7.5 HP	7.5 HP	10 HP	15 HP	20 HP

Standard Equipment

• Standard Main Drive Motor.
• Standard Panel Board Accessories.
• Stroke Counter.
• Electrical Control Panel.
• Front sheet support.
• Squaring arm with steel rule.
• Hardened Transfer bars mounted on table.
• Cutting area illuminated for clear view of blades.

Gurmeet Machinery Corporation is one of the trustworthy Shearing Machine Manufacturers In Punjab who is here to fulfill all your machine tools needs. We have a key objective to be a one-stop shop for all your needs of machines that are used in shaping, cutting, and drilling metals. We believe in building valuable business relationships. We have Shaper Machine, Surface Grinder Machine, Hydraulic Press Machine, Shearing Machine, Milling Machine, and much more for you. Our focus is to be a trusted platform in the domain.

 We have an in-house manufacturing unit with new machines, and modern technology is established for designing the unmatched quality Shearing Machine in the town. With innovation and better technology, we became a one-point solution for Shearing Machine. We have an ISO 9001-2015 Certificate issued by the Dubai Accreditation Centre that speaks for the quality of our products. Our highly trained expert supervises every detail during manufacturing and keeps their figures on the pulse to bring the best quality products for you. Our consistent efforts and excellence enable us to earn credibility in the domain. The hard work and dedication to achieve something in life permit us to attain maximum client satisfaction. We are the ones who strictly follow the industry norms and never compromise with the quality standard.

We work next level hard to attain the name of one of the leading Shearing Machine Exporters And Suppliers In India and pay attention to every detail to enhance the performance of our machines. You can place your trust in our Shearing Machine and reach us anytime for the same. We offer you the best products at the best possible price so call us without further delay. We are committed to delivering premium products in the minimum time. Our experts are right here to assist you in the best ways. Connect with us over a call or drop an email. We are happy to help you. Ping us now.
